| Vehicle parameters | Overall dimension | 10250*2500*3750mm | |
| Weight | 23000kg | ||
| Chassis brand | HOWO | ||
| Drive type | 4×2 | ||
| Engine model | WP10.300E40 | ||
| Output power | 225kw/2200rpm | ||
| Emission standard | Euro IV | ||
| Tyre | 295/80R22.5 | ||
| Boom & Outrigger parameters | Boom vertical height | 38m | |
| Boom horizontal length | 33.5m | ||
| Boom vertical depth | 22m | ||
| Boom folding form | 5RZ | ||
| First boom | Length | 7500mm | |
| Corner | 90° | ||
| Second boom | Length | 6200mm | |
| Corner | 180° | ||
| Third boom | Length | 6100mm | |
| Corner | 180° | ||
| Fourth boom | Length | 6700mm | |
| Corner | 229° | ||
| Fifth boom | Length | 6700mm | |
| Corner | 212° | ||
| End conveyor hose | Length | 3m | |
| Turntable rotation angle | ±360° | ||
| Front outrigger deployment width | 6800mm | ||
| Rear outrigger deployment width | 8350mm | ||
| Longitudinal distance between front and rear outrigger | 6800mm | ||
| Outrigger opening method | Front outrigger | X-shaped | |
| Rear outrigger | Swinging | ||
| Pumping system parameters | Theoretical concrete displacement | Low pressure | 140m³/h |
| High pressure | 83m³/h | ||
| Theoretical pumping pressure | Low pressure | 8MPa | |
| High pressure | 12MPa | ||
| Theoretical pumping frequency | Low pressure | 39 | |
| High pressure | 23 | ||
| Distribution valve form | S valve | ||
| Inner diameter/stroke of conveying cylinder | 230/1550mm | ||
| Main oil pump displacement | 190ml/r | ||
| Bucket capacity | 0.5m³ | ||
| Feeding height | 1450mm | ||
| Inner diameter of conveying pipe | 125mm | ||
| Max. aggregate size | 40mm | ||
| Concrete slump | 160-220mm | ||
| System oil pressure | 31.5MPa | ||
| Hydraulic oil capacity | 400L | ||
| Hydraulic system type | Open | ||
| High and low voltage switching | Automatic switching | ||
| Hydraulic oil cooling method | Forced air cooling | ||
| Cleaning method for concrete pipes | Water wash | ||
| Lubrication method | Centralization lubrication | ||
| Spare parts brand | Transfer box | Zhuzhou Gear | |
| Main oil pump | REXRTOH | ||
| Boom pump | PUSH | ||
| Constant pressure pump | PUSH | ||
| Gear pump | Wany | ||
| Boom multi way valve | Km Hydraulic | ||
| Boom balance valve | REXRTOH | ||
| Valve group | EATON | ||
